Conical Reducer

Description

Tube OD : 3/8 to 2″ inches (9.53 to 50.8 mm)
Tube Finishes : Beadblast (Tumbled Standard & Electro finishes available upon request)
Material : 304 Standard (304L, 316 & 316L available upon request)
O-Rings : Viton Standard (Buna & Silicone available upon request)
Fasteners : Wing nut & bulkhead clamps – Aluminium
Vacuum Range : Elastomer seal: ≥1 x 10^-8 mbar – High Vacuum
Temperature Range :
- Viton: -20°C to 200°C
- Buna: -30°C to 110°C
- Silicone: -50°C to 230°C

Part Number	Flange (CF)	A	Bolt Holes	Bolt Diameter
ST-CF-133025N	1.33 (33.78	0.255 (06.48)	6	0.172 (4.37)
ST-CF-133038N	1.33 (33.78)	0.380 (09.65)	6	0.172 (4.37)
ST-CF-133050N	1.33 (33.78)	0.505 (12.83)	6	0.172 (4.37)
